Resources

""

The Biomolecular NMR Shared Resources currently operates six high field NMR spectrometers, four configured for solution NMR and two configured for solid state NMR.

The capabilities and main applications of each of spectrometers are described below.



  • Avance II DRU Bruker spectrometer.
  • 2.2k degree actively shielded 54mm bore super conducting magnets.
  • Variable temperature control.
  • 5 channel operation.
  • Digital receiving / digitizing capabilities
  • Linux based PC control workstation.
  • 5mm HCN triple resonance cryoprobe yielding ultra high sensitivity.
  • 13C observe capability with increased sensitivity.

  • Conventional high resolution probe(s).



  • Avance NEO Latest generation Bruker spectrometer.
  • 4.7k actively shielded 54mm bore magnet.
  • Variable temperature control.
  • 5 channel operation.
  • Advanced digital receiving / digitizing capabilities.
  • Linux based PC control workstation.
  • 5mm HCN triple resonance cryoprobe.
  • 13C observe capability with increased sensitivity.
  • Conventional high resolution probe(s).

  • Avance III HD modern generation high dynamic range Bruker spectrometer.
  • 4.7k actively shielded 54mm bore magnet.
  • Variable temperature control.
  • 5 channel operation.
  • Advanced digital receiving / digitizing capabilities.
  • Linux based PC control workstation.
  • 5mm HCN triple resonance cryoprobe.
  • 13C observe capability with increased sensitivity.
  • Conventional high resolution probe(s).

  • Avance II DRU Bruker spectrometer.
  • 4.7k actively shielded 54mm bore magnet.
  • Variable temperature control.
  • 5 channel operation.
  • Advanced digital receiving / digitizing capabilities.
  • Linux based PC control workstation.
  • 5mm HCN triple resonance cryoprobe.
  • 13C observe capability with increased sensitivity.
  • Conventional high resolution probe(s).
  • Sample Jet Automation.

  • Avance early generation Bruker spectrometer.
  • 4.7k degree actively shielded 89 mm bore magnet.
  • 28 or 34 gradient orthogonal shim system operation.
  • Variable temperature control.
  • 4 channel operation.
  • Solid-State NMR (CPMAS, Static and HRMAS).
  • Ultra-low temperature MAS equipped.

  • Avance III HD modern generation high dynamic range Bruker spectrometer.
  • 4.7k Actively shielded 89 mm bore magnet.
  • Variable temperature control.
  • 4 channel operation.
  • Solid-State NMR (CPMAS, Static and HRMAS).
  • Ultra-low temperature MAS equipped.
